Opis
Marin Alpine Trail E2 z BOSCH motorjem, je novo kolo, narejeno za vse tiste, ki se radi spuščajo po najbolj zahtevnih terenih, z novim Bosch motorjem pa lahko peljete ne samo po klancih navzdol, ampak tudi po najzahtevnejših klancih navzgor. Vožnja v hrib je s tem kolesom ravno tako zabavna kot spust s hriba. Je najboljše električno kolo. Vse komponente so izbrane tako, da omogočajo vožnjo brez kakršnihkoli kompromisov.
Tehnične specifikacije
| Okvir |
All New, Series 4 Alloy, 160mm MultiTrac Suspension LT, Adjustable Headset & CS Length/Height, Integrated Battery/Charging Port, 148mm Rear Thru-Axle |
| Sprednje vilice | Marzocchi Z1, 170mm, 29", 110x15 Kabolt Thru Axle, 44mm Offset |
| Zadne vzmetenje |
Marzocchi CR Coil, 205x65mm, Trunnion Upper Mount, 30xM8 Lower Hardware, Custom Tune, M Spring Rate = 450lb, L Spring Rate = 500lb, XL Spring Rate = 550lb |
| Obroči |
Front: Marin Aluminum Double Wall, 29" Diameter, 32mm Inner Rim Width, Pinned Joint, Disc Specific, Tubeless Compatible; Rear: Marin Aluminum Double Wall, 27.5" Diameter, 32mm Inner Rim Width, Pinned Joint, Disc Specific, Tubeless Compatible |
| Zadnja pesta |
Shimano HB-TC500, 148x12mm, Centerlock, Standard Freehub Body |
| Prednja pesta |
Shimano FH-TC500, 110x15mm, Centerlock, 32H |
| Napere |
14g Black Stainless Steel |
| Plašči |
Vee Tire Co Attack HPL, E-Control Compound, Front 29x2.5", Rear 27.5x2.5" |
| Zadnji menjalnik |
Shimano CUES RD-U6000 GS, 10-Speed |
| Prednji menjalnik | - |
| Prestavne ročice |
Shimano CUES SL-U6000-10R, 10-Speed |
| Gonilke |
e*thirteen e*spec Plus, 160mm Length |
| Motor |
Bosch Performance Line CX, 85Nm |
| Baterija | Bosch PowerTube 750 Wh |
| Zaslon | Bosch BRC3100 Systems Controller |
| Switch | Bosch BRC3300 Bluetooth Remote 22.2mm Clamp |
| Veriga |
Shimano LG500 |
| Verižnik | Shimano CS-LG300-10, 11-48T |
| Prednje zavore |
TRP Slate EVO 4-Piston Hydraulic, 203mm Rotor, 2.3mm Thick |
| Zadnje zavore | TRP Slate EVO 4-Piston Hydraulic, 203mm Rotor, 2.3mm Thick |
| Zavorne ročice |
TRP Slate EVO |
| Krmilo | Marin Mini Riser, 6061 Double Butted Aluminum, 780mm Width, 28mm Rise, 5º Up, 9º Back |
| Nosilec krmila |
Marin 3D Forged Alloy, 35mm |
| Grips |
Marin Grizzly Lock On |
| Krmilni ležaj |
FSA Custom Headset, Adjustable HTA Design |
| Sedežna opora |
TranzX, YSP39 1x Remote, 34.9 Seatpost Diameter, Travel S = 150mm, M/L = 170mm, XL = 200mm |
| Sedež |
Marin Speed Concept |
| Pedala | - |
